    30W LED Retrofit Kits for 105W Metal Halide Fixtures Parking Lot Lighting Retrofit

      (9 Reviews) | Write a review
    SKU: LSRK-30WXY-WH

    Please Choose:



    Discontinued
    Starting at: $136.95
    • 30 Days Return
    • 5 Years Warranty
    Add to Wishlist
    Deliver between Sat,Dec,14 and Fri,Dec,20. order with 2days,9hrs and 31 min.

    30W LED retrofit kit, 143LM/W high efficiency, ETL cETL DLC CE RoHS certified. Rotatable angle and E40 E39 E27 E26 base allows the retrofit kit to adapt to a wide range of luminaires. Widely used in replacing HID, MH bulbs in Shoebox, Wall pack, Canopy, High Bay, Cobra head Street fixtures.

    Feature

    • 5 years warranty.
    • 0-10V Dimmable Optional.
    • Various beam angle of 120 degree.
    • Original Lumileds 3030 LEDs which is up to 143Lm/W.
    • Arm adjustable with any beam angle.
    • With a big Sunon fan(60,000hours).
    • Body Temperature:<55 oC  @Ta=25 oC
    • With the most excellent quality meanwell driver.
    • Available with both 100-300VAC & 347VAC & 480VAC.
    • Using aluminum fin heat sink which heat transfer faster than die cast.
    • Tiny package and lighter,lower freight cost,more competitive in the market.
    • Avaialble for low bay fixture,street pole,canopy,parking lot shoebox,wall pack,high bay fixtures etc.
    • ETL DLC CE Lm79 Lm80.

    Warranties & Certifications


    Specifications
    Watt:    30W
    Lumen:    4,300 Lumen
    Efficiency:     143Lm/W±3%
    Chip Brand:    Lumileds 3030
    Input Volt:    100-277VAC
    Driver:    Sosen Driver SS-30VA-56
    CCT:    3000-6000K
    Size:    315*149.6mm
    Weight:    0.8kg
    Fan:    Without
    Base:    E40/ E39(mogul)/ E26/ E27(Medium)
    Equivalent:    75W  to 105W metal halide / HID lamp Equivalent
    Power Factor:    >0.95
    Beam Angle:    120 degrees
    IP Rating:    IP60
    CRI:    >80
    Working Tempe / Humidity:    -45 to + 50 Deg C / @Ta=25 Deg C
    Warranty:      5 year Warranty
    Rated Lifespan:    50,000+ hours
    Certified:    ETL DLC CE Lm79 Lm80


    View Dimensional Drawings

    1.Sunon fan(30W are without fan); 2.Hexagon heat sink; 3.E40 to E27; 4. Aluminum heat sink; 5.Lumileds 3030;
