Cool White 8mm through hole LED. Features 11,000 millilumens and a cool white color temperature of 5250K. This unique LED has a diffuser coating which emits Red light in all directions, 360 degrees around, from end and bottom, just like a filament bulb. Component LEDs are sensitive electronic devices and require some knowledge of electronic circuits to operate them. Price listed is per unit, however, bulk discounts are available and are automatically applied to your order.

Dimensional Drawings

TECHNICAL DETAILS
Color Temperature:    5250 K
Continuous Forward Current:    60mA
Forward Voltage:    3.2V
LED Color:    Cool 5250K
LED Package:    8 mm
Lens:    Diffused
Lumen:    11 Lumen
Maximum Forward Voltage:    3.3V
Millicandela:    900mcd
Operating Temperature:    -20~+80 °C (-4~+176 °F)
Peak Forward Current:    100mA
Reverse Current:    100mA
Reverse Voltage:    5V
Storage Temperature:    -30~+100 °C
Total Power Consumption:    0.192 Watts
Viewing Angle:    360 degree
Package Weight: 0.02oz (0kg)
Package Dimensions: 0.47" (1cm) x 0.36" (1cm) x 0.36" (1cm)

Applications / Uses
Industrial controls, Medical equipment, Communications equipment, Test and measurement, Security electronics.
